Welded Gabion Walls

Product specification

Feature	Details
Material	steel wire
Wire diameter	ø4mm
Hole opening	50x100mm
Finish	Whole hot dip galvanized after welding
Price	EXW China factory US$6/m²

Description

Welded gabion, along with its related products such as welded gabion mesh, gabion walls, gabion welded wire mesh, and welded wire gabion barriers, has become a preferred choice in various construction and landscaping projects. With its excellent performance, aesthetic appearance, and long – term durability, it plays an important role in both practical and decorative applications.

1. High – Quality Raw Materials

The production starts with the high quality low carbon steel wire, which is known for its outstanding mechanical properties. This type of steel wire has good toughness and strength, enabling the final welded gabion products to withstand external forces such as pressure and impact. Moreover, low – carbon steel wire has excellent weldability, ensuring a firm connection between each wire during the welding process, thus laying a solid foundation for the overall stability of the products.

2. Advanced Production Process

The manufacturing of welded gabion mesh adopts an advanced automatic welding process. First, the selected low – carbon steel wires are straightened and cut into fixed lengths according to the required specifications. Then, the wires are arranged in a horizontal and vertical manner to form a grid structure. Next, the intersection points of the horizontal and vertical wires are welded together using high – frequency welding technology.

This welding method ensures that each welding point is firm and uniform, with high bonding strength, effectively preventing the wires from falling off or loosening. After welding, the mesh is cut into different sizes to meet the needs of various walls and welded wire gabion barriers. The entire production process is strictly controlled by professional technicians to ensure the consistency and quality of each product.

3. Surface Hot – Dip Galvanizing Process

To enhance the corrosion resistance and service life of welded gabion products, we apply a surface hot – dip galvanizing process. First, the welded gabion mesh is thoroughly cleaned to remove oil, rust, and other impurities on the surface. Then, it is immersed in a molten zinc bath at a high temperature (about 450°C). During this process, a dense zinc coating is formed on the surface of the steel wire.

This zinc coating acts as a protective barrier, isolating the steel wire from the external environment such as moisture, oxygen, and chemicals, thereby preventing corrosion. The hot – dip galvanizing process not only improves the durability of the welded gabion but also gives it a bright and uniform appearance, enhancing its aesthetic value. The galvanized layer has strong adhesion and is not easy to peel off, ensuring long – term protection for the product.

4. Product Specification Range

Our welded gabion products have a wide range of specifications to meet different project requirements. In terms of wire diameter, we offer options from 3mm to 6mm. The 3mm wire diameter is suitable for lightweight applications such as small – scale landscape decoration, while the 6mm wire diameter is ideal for heavy – duty projects like slope protection and riverbank reinforcement, providing strong support.

For the mesh hole size, the recommended range is 50mm to 200mm. The 50mm mesh hole is suitable for projects that require high precision and small filling materials, such as retaining walls for small gardens. The 200mm mesh hole is more suitable for large – scale projects, allowing the use of larger stones as filling materials, which not only reduces the cost but also ensures the stability of the structure.

In addition, we can also customize the specifications of welded gabion walls and welded wire gabion barriers according to the specific needs of customers, including length, width, and height.

5. Outstanding Product Features

One of the most prominent features of welded gabion products is their neat, concise, and aesthetic appearance. The uniform grid structure formed by the automatic welding process makes the product look regular and tidy. When used in outdoor landscaping projects, such as garden borders, landscape walls, and artificial waterfalls, It can blend perfectly with the surrounding environment.

It is also highly suitable for outdoor landscaping. It can be flexibly designed and constructed according to the design concept of the landscape project. Whether it is a small – sized decorative structure or a large – scale landscape engineering facility, welded gabion can meet the requirements. For example, in the construction of a garden rockery, welded gabion mesh can be used to form the framework, and then filled with various sizes of stones to create a natural and realistic rockery shape.

Contact Us

Additional information

Material	Steel wire
Wire Diameter	ø4mm
Hole opening	50x100mm
Finish	Whole hot dip galvanized after welding
Price	EXW China factory US$6/m²
